JaxxGTA Kustom Kwads


Welcome to my store. Here you will find a selection of mini quadcopters designed to be light, functional and stylish.

I specialise in Design, 3D Modelling and Photo Realistic Rendering. Contact me via email at dwgserv@gmail.com for any queries.



Kits

  • product
    More Details

    MantaRay 240 Mini Quadcopter Frame Kit

    $ 52.00

    Introducing the MantaRay 240

    • A True X frame design with 240mm motor to motor
    • A unique Spine plate for better mounting options and a cleaner build
    • Cutout & holes for mounting an XT60 using this holder
    • Support for 5 inch props
    • Camera side plates to support HS1177 style camera
    • 3mm thick unibody baseplate
    • 1.5mm thick top plate
    • Weight is 102g incl. hardware
    • Motor mount hole support for 18xx to 22xx
    • 30.5mm spacing for PDB and Flight controller mounting.

    Spare parts can be purchased separately in my store







  • product
    More Details

    BarraCuda 210 v1.1 Mini Quadcopter Frame Kit

    $ 51.48

    Introducing the BarraCuda 210 v1.1

    • An X frame design with 210mm motor to motor
    • A unique Spine plate for better mounting options and a cleaner build
    • Cutout & holes for mounting an XT60 using this holder
    • Support for 5 inch props
    • Camera side plates to support HS1177 style camera
    • Super rigid & strong yet light weight construction
    • 2mm thick Top & Bottom Plates
    • 4mm thick Arms
    • Includes optional bracing plate for those who push the envelope and need extra crash protection
    • Weight is 103g incl. hardware
    • Motor mount hole support for 18xx to 22xx
    • 30.5mm spacing for PDB and Flight controller mounting.

    (Please note the purple anodized hardware shown is not currently available directly from Armattan Productions but is available from various other online stores. Standard steel hardware and black aluminum standoffs are supplied in this kit.)

    Spare parts can be purchased separately in my store



  • product
    More Details

    MantaRay 180 Mini Quadcopter Frame Kit

    $ 45.08

    Introducing the MantaRay 180

    • A True X frame design with 180mm motor to motor
    • A unique Spine plate for better mounting options and a cleaner build
    • Cutout & holes for mounting an XT60 using this holder
    • Support for 4 inch props
    • Camera side plates to support HS1177 style camera
    • 3mm thick unibody baseplate
    • 1.5mm thick top plate
    • Weight is under 75g
    • Motor mount hole support for 18xx to 22xx
    • 30.5mm spacing for PDB and Flight controller mounting.

    Spare parts can be purchased separately in my store

  • product
    More Details

    BarraCuda Sixxer Frame Kit

    $ 54.40

    Introducing the BarraCuda Sixxer

    (Based on the popular BarraCuda 210 but with extended arms to fit 6" props)

    • An X frame design with 255mm motor to motor for 6" props
    • A unique Spine plate for better mounting options and a cleaner build
    • Cutout & holes for mounting an XT60 using this holder
    • Camera side plates to support HS1177 style camera
    • Super rigid & strong yet light weight construction
    • 2mm thick Top & Bottom Plates
    • 4mm thick Arms
    • Includes optional bracing plate for those who push the envelope and need extra crash protection
    • Weight is 115g incl. hardware
    • Motor mount hole support for 18xx to 22xx
    • 30.5mm spacing for PDB and Flight controller mounting.

    Spare parts can be purchased separately in my store



  • product
    More Details

    BarraCuda 210 V2.2

    $ 58.42

    Introducing the BarraCuda 210 v2.2

    Version 2.0 has the following improvements:

    • Design of the top and bottom plates have been optimized to reduce weight & cost slightly while retaining structural strength and stiffness
    • Top and Bottom plates have been extended by 10mm to allow use of the popular 1800mah batteries for longer flight times
    • All tolerances have been reduced to ensure a very tight fit between parts. However due to slight variences in production runs occasionally some lite sanding of tabs may be required

    The rest of the specs are as per V1.1

    • An X frame design with 210mm motor to motor
    • A unique Spine plate for better mounting options and a cleaner build
    • Cutout & holes for mounting an XT60 using this holder
    • Support for 5 inch props
    • Camera side plates to support HS1177 style camera
    • Super rigid & strong yet light weight construction
    • 2mm thick Top & Bottom Plates
    • 4mm thick Arms
    • Includes optional bracing plate for those who push the envelope and need extra crash protection
    • Weight is 100g incl. standard steel hardware (excl. optional bracing plate @ 3.6g)
    • Motor mount hole support  the popular 18xx & 22xx size motors
    • 30.5mm spacing for PDB and Flight controller mounting.

    (Please note the purple anodized hardware shown is not currently available directly from Armattan Productions but is available from various other online stores. Standard steel hardware and black aluminum standoffs are supplied in this kit.)

    Spare parts can be purchased separately in my store
