Atom 33

A 3 inch super stiff 3mm frame for pure acro flying.

Configuration shown in picture uses GNB 450mAh 2s with Flywoo 1103-7650 and 3015/3018 props, which gives 5 minutes of punchy precise acro flight.

Alternatively fit any motor with 9mm mounting and battery of your choice, and enjoy.

The frame is 120mm wheelbase and 3mm thick, the cut is along the weave for maximum strength and stiffness.

Frame: 120mm wheelbase, 3mm carbon. Cut along weave for maximum strength.

Frame Weight: 9.52 grams (0.33oz)

Motors: Flywoo 1103-7650Kv, or any 9mm mounting.

FC: AIO F4 whoop 10-20 Amp. 25.4mm or 26.5mm mounting holes (NLRC AIO 412T flight controller used).

Battery: 2s 450mAh GNB used, or 2-3s 450-550mAh.

Camera: Eachine TX06 AIO or equivalent.

Canopy: 25 degree 3D printed (See PlainFlight on Thingiverse.com).

Battery Strap: 3D printed & coming soon (See PlainFlight on Thingiverse.com).

AUW: 47 grams (no Battery).

ESC Firmware: Jazz Maverick 24KHz preferred.
