Frame Size: ~167mm motor to motor Layout: X Bottom Plate: 4mm Carbon Top Plate: 2mm Carbon Cam mount Plate: 1mm Carbon Max Prop size: 4" Motor Mounting: Standard Φ12 in M2 Mounting Screw (common 1407 sized motors) FC Mount : 30.5x30.5mm or 20x20mm Camera size type : Micro (19mm width) Weight: ~40g (carbon weight, without hardware)
Kit only includes carbon fiber components. Required Hardware (not included):
(4x) 25mm height standoffs (M3 screw)
(4x) M3 x 8mm Screws
(4x) M3 x 5mm Screws
Motor Screws : (16x) M2 x (minimum 6mm + soft mount height)
